Gas Cooling Chiller

AIR COOLED CHILLERS

Note: Air Cooled Chillers can be customized explosion-proof.

Air cooled chillers use shell and tube evaporators to exchange heat between water and    refrigerant. The refrigerant system absorbs the heat in the water. After cooling the water,    the heat is brought to the condenser through the compressor, and then dissipated to the    outside air by the cooling fan.

Characteristics of Air-cooled Chillers：
1.The air-cooled chiller does not need to be connected to a cooling tower, and is suitable for environments with poor impurities. (Impurities are easily mixed in the cold water tower, and the dust will cause the cooling water circulation circuit to be blocked, resulting in a decrease in cooling capacity).
2. Air-cooled chillers are most suitable for areas with poor water quality, which can save other accessories such as cold water towers.
3. The use of large-capacity condenser makes it easier and more convenient to operate.
4.The floor space is reduced to a greater extent, and the installation is very convenient.
5. The air-cooled chiller adopts the design of the upper air outlet.
6. Temperature Control Range -152℃~250℃


Customized Solution
Sample Download

Ultra-low Temperature For Refrigerated

ModelCooling Capacity  Circulation PumpCapacity of Liquid Storage Power 220V 380V
LT -45℃～30℃0.4KW~12KW20L/min0.7BAR~75L/min1BAR15L~80L1.6kW~8kW
LT -60℃～-20℃0.4KW~7.2KW20L/min0.7BAR~75L/min1BAR15L~60L2.5kW~9kW
LT -80℃～-20℃0.2KW~7.2KW20L/min0.7BAR~75L/min1BAR15L~60L3kW~11.5kW
LX -25℃～30℃0.8KW~38KW20L/min1.5BAR~250/min2.5BAR15L~300L1.5kW~17kW

High & Low Temperature For Reaction

ModelCooling Capacity  Heating PowerCirculation PumpPower 220V 380V
SUNDI -10℃~200℃1.5kW~15kW2.5kW~15kW20L/min 2bar~75L/min 2.5bar3.6kW~20kW
SUNDI -25℃~200℃1kW~200kW2.5kW~200kW20L/min 2bar~600L/min 2.5bar4kW~260kW
SUNDI -25℃~300℃1kW~200kW2.5kW~200kW20L/min 2bar~600L/min 2.5bar4kW~260kW
SUNDI -45℃~250℃0.45kW~200kW3.5kW~200kW35L/min 2bar~600L/min 2.5bar6.5kW~280kW
SUNDI -60℃~250℃2.5kW~60kW0.25kW~60kW20L/min 2bar~250L/min 2.5bar5kW~95kW
SUNDI -70℃~250℃0.4kW~15kW2.5kW~15kW20L/min 2bar~110L/min 2.5bar5.2kW~28kW
SUNDI -25℃~200℃ 1&21kW*2~10kW*22.5kW*2~10kW*220L*2/min 1.5bar~50L*2/min 2bar7.5kW~31kW
SUNDI -40℃~250℃ 1&20.45kW*2~10kW*22.5kW*2~10kW*220L*2/min 1.5bar~60L*2/min 2bar8kW~33kW

High &Low Temperature For Semiconductor Test

ModelHeating PowerRefrigerating OutputTemp. control AccuracyPowerCirculation Pump
TES -45℃~250℃2.5kW~25kW0.25kW~25kW±0.3℃6kW~36kW20L~150L/min2.5bar

High &Low Temperaute For Vehicle Test

ModelHeating PowerCooling CapacityTemp. Control AccuracyPower
KRY  -40℃~+100℃5.5kW~38kW1.2kW~60kW±0.5℃12kW~82kW
KRY 0℃~+100℃2.5kW~38kW1.8kW~60kW±0.5℃6.5kW~50kW
KRY -25℃~+100℃5.5kW~25kW2.8kW~38kW±0.5℃11kW~45kW

You can contact us for custom temperature solutions. Just state your needs.

Plastic industry: accurately control the mold temperature of all kinds of plastic granulation, reduce the beer molding cycle time, and ensure the stability of product quality.

       Electronic industry: stabilize the molecular formula of electronic components in the production line, improve the standard rate of electronic components, apply it to the field of    ultrasonic cleaning, and reasonably avoid the damage caused by the evaporation and evaporation of expensive detergent.

       Electroplating field: control the electroplating temperature, improve the relative density and smoothness of plated parts, reduce the electroplating cycle time, improve    productivity and improve product quality.

       Mechanical Engineering: control the working pressure and oil temperature of steam pressure system software, stabilize the water temperature and steam pressure, increase the    service time of oil products, improve the high efficiency of lubrication of mechanical equipment and reduce wear.

       Industrial production of Engineering Construction: provide chilled water for concrete, make the molecular formula of concrete suitable for the main purpose of engineering    construction, and reasonably improve the strength and ductility of concrete.

       Vacuum plating: control the temperature of vacuum coating machine to ensure the high quality of plated parts.

       Chemical and Pharmaceutical industry: in the medical industry, the key is to control the temperature control of hair alcohol drugs. Pharmaceutical manufacturing enterprises    should flexibly use the chiller equipment, effectively strengthen technological innovation on the basis of giving full play to its advantages, improve the cost performance of the    chiller, and then better serve the projects in the pharmaceutical industry.

       Laser industry: used in laser marking machines, laser engraving machines, laser welding machines, laser inkjet printers, laser cutting machines and other laser processing    equipment to accurately control the temperature required by the laser equipment to ensure the normal operation of the laser equipment.
